The Gotham 11201 GAC‑4/1 FRNC is a professional-grade 5.4 mm Star‑Quad microphone cable designed for maximum RF immunity and fire-safe performance. It features four finely stranded bare copper conductors (96 × 0.05 mm each, approx. 0.19 mm²) with low-capacitance polyethylene insulation, precisely arranged in a star‑quad geometry to maintain consistent spacing and halve signal loss. The core is wrapped with viscose fiber and shielded by dual Reussen-style bare copper braids, each offering 100% coverage, resulting in RF rejection in excess of 130 dB at 25 kHz. Housed in a halogen-free, flame-retardant (FRNC) black outer jacket, it provides outstanding flexibility and durability. With conductor resistance under 90 Ω/km, shielding resistance below 20 Ω/km, capacitance under 55 nF/km (between conductors) and 103 nF/km (conductor-to-shield), and a side‑circuit capacitance of 55 pF/m (135 pF/m quad), it ensures clear, consistent audio over long runs. Rated for test voltages of 500 V between conductors and 2,000 V conductor-to-shield, and flexible from –5 °C to +50 °C (–30 °C to +70 °C in fixed installations), it’s ideal for professional stage, studio, broadcast, and installation environments demanding both fire safety and superior signal integrity.

This cable is ideal for: XLR, TRS, and other balanced audio connectors - especially in installation environments where fire resistance is paramount.

1 = FRNC Material
2 = Shield No. 1: Bare copper wires (0.10 mm) 100% coverage
3 = Shield No. 2: Bare copper wires (0.10 mm) 100% coverage
4 = Viscose fiber coat: counter wrapped to the quad twisted conductors
5 = Insulation (cond): PE, Ø 1.2 mm, white, red, ivory, pink, quad-twisted
6 = Conductor: Stranded bare copper wires 96 x 0.05 mm (0.19 mm²)96x44AWG = 24 AWG

Conductor Resistance: < 90 ohm/km
Shielding Resistance: < 20 Ohm/km
Capacitance (Conductor-Conductor) <55 nF/km
Capacitance (Conductor-Shield) <103 nF/km
Side Circuit Capacitance (Single) 55 pF/m
Side Circuit Capacitance (Quad) 135 pF/m
Noise Attenuation 130 dB (see wiring)
Characteristic Impedance 20 kHz
Test voltage (cond/cond): 500 (RMS)
Test voltage (cond/shield): 2000 (RMS)
Operating voltage low voltage
Temperature range (flexi-installed): -5° to +50° C
Temperature range (fix-installed): -30° to +70° C
