The Gotham 12001 GAC‑2 Pair is a professional-grade 8.0 mm flat stereo cable engineered for superior crosstalk rejection and flexibility in high-density recording and installation applications. Each channel features a 0.19 mm² stranded bare copper conductor (25 × 0.10 mm), insulated with polyethylene and color-coded red (right) and white (left). These conductors are housed together in a dark grey PVC jacket (4.0 × 8.0 mm) and each pair is protected by dual 100% bare copper Reussen-style braid shields. With conductor resistance under 90 Ω/km, shielding resistance below 20 Ω/km, capacitance under 75 nF/km between conductors and 130 nF/km to shield, and rated for 500 V conductor-to-conductor and 2,000 V conductor-to-shield tests—operationally flexible from –5 °C to +50 °C (–30 °C to +70 °C fixed)—this cable provides dependable, professional-quality stereo performance in demanding studio and installation environments.

This cable is ideal for stereo balanced cable operations requiring tight installations and sleek cable management.

1 = Jacket: (Ø 4.0 x 8.0 mm), grey (dark)
2 = Shield No. 1: Bare copper wires (0.10mm), 100% coverage
3 = Shield No. 2: Bare copper wires (0.10mm), 100% coverage
4 = Insulation (cond): PE, Ø 1.15 mm, conductors red and white wrapped
5 = Conductor: Stranded bare copper wires 25 x 0.10 mm (0.19 mm²) 25x38AWG = 24AWG

Conductor resistance: < 90 ohm/km
Shielding resistance: < 20 Ohm/km
Capacitance at (800Hz) - Conductor/Conductor) < 75 nF/km
Capacitance at (800Hz) - Conductor/Shield < 130 nF/km
Temperature range (flexi-installed) -5° to +50° C
Temperature range (fixed-installed) -30° to +70° C
