The Gotham 50025 PVC 2×2.5 mm² is a professional-grade dual-conductor speaker cable designed for robust, high-fidelity audio transmission. It consists of two fine-stranded LFOC copper cores (2.5 mm² each) sheathed in rugged PVC insulation, delivering conductor resistance below 7 Ω/km and insulation resistance exceeding 200 MΩ/km. The cable’s capacitance is approximately 100 pF/m between conductors, minimizing signal attenuation, while its 2,000 V test rating and 300 V maximum operating voltage ensure electrical durability. With current handling up to around 14 A (≈ 3,150 W) and operational flexibility from –5 °C to +50 °C (–30 °C to +70 °C fixed), this cable offers a balanced solution of flexibility, resilience, and audio integrity for studio monitors, PA systems, and loudspeaker installations.

This cable is ideal for any unbalanced coaxial loudspeaker installation.

1 = Jacket: Flameretarded PVC, Ø 8.0 mm, black [Flame-Retardant PVC Jacket (IEC 60332-3)]
2 = Insulation: PVC, Ø 3.2 mm, black und red
3 = Conductor: (OFC) Stranded bare copper wires 140 x 0.15mm (2.50mm²) 140x34AWG = 13 AWG

Conductor Resistance: < 7.3 ohm/km
Test Voltage: 2000 (RMS)
Temperature Range (Flexi-Installed): -5° to +50° C
Temperature Range (Fixed-Installed): -30° to +70° C
Maximum Watts Load (@ current 15.0 Ampere/Line) < 1650 Watt
