The Gotham 85015 is a professional-grade, shielded mains power cable (3 × 1.5 mm²) engineered for ultra-flexible, low-noise power delivery to high-end audio systems. Each conductor features 27-strand OFC copper (approx. 1.5 mm²), wrapped in PE insulation and housed within a marine-blue PVC jacket (~7.6 mm Ø). It includes a double-layer shield: a copper-coated polyester foil (K6160) and a full Reussen-style bare copper braid with an integrated tinned-copper drain wire. This construction ensures protection against 50 Hz hum and RF interference, keeping adjacent audio cabling clean. With conductor resistance < 13.3 Ω/km, it handles up to 9 A per line (~950 W load), rated for 230–240 VAC operation, tested to 2,000 V, and remains flexible between –30 °C and +70 °C. Ideal for audiophile-grade power cords or cleanly shielded mains routing in studios, performance rigs, and high-fidelity installations.

This cable is ideal for delivering power to mains & high-end audio gear.

1 = Jacket: PVC (YM2) 1.1mm. Ø 7.60 mm max., ultrablue RAL5013
2 = Wrapping: Non woven fabric tape
3 = Shield #2: Bare copper wires (0.15 mm) 100% coverage S
4 = Drain Wire: 16x0,19mmØ Cu (Ground) bare copper
5 = Shield #1: K6160 Polyester nonwoven thermally bonded, both sides copper coated (see below)
6 = Insulation 3x: PE – 2YI 1, 0.43mm thickness. Nominal Diameter 2.40 mm. Color code: Blue-Brown-Yellow/Green
7 = Conductor 3x: 27x0,25mmØ "OFC" Cu 1,50mm² bare copper stranded 27x30AWG (16AWG)
IEC 60228 Class 5 flexible copper conductor 1,50mm²

Conductor Resistance: < 13.30 Ohm/km
Rating Voltage: 300/500V
Test Voltage: 2000 (RMS)
Temperature Range: -30° to +70° C
Maximum Watts Load (@ Current 9.0 Ampere/Line) < 950 Watt
